Today, for the very first time on this channel, we will be talking about an engine coming from China. A mass-produced gasoline engine developed and built in China by automotive giant Geely. This engine achieves an incredible thermal efficiency of 48.41%. Of course, with this efficiency, it’s not surprising that this engine also powers the current Guinness World Record holder for the most fuel-efficient mass-produced hybrid (non-plug-in) vehicle.
Allow me to put the thermal efficiency into perspective: the best Toyota has achieved in their latest generation of dynamicforce engines is 41%. Nissan achieved 42% in their e-power system, where the engine only ever acts as a generator.
Improving efficiency beyond 40% is an area of ridiculously diminishing returns. A 1% improvement here is already massive, yet Geely somehow managed to outperform Toyota by an incredible 7.4%, and in this video we will explain exactly how that was done.
First up, the very heart of the engine, the bore and stroke. Unfortunately, we don’t know the exact bore and stroke because Geely never published it, but they have published the engine displacement, number of cylinders and the stroke-to-bore ratio of 1.39:1, which tells us that the stroke is 39% larger than the bore. Based on these numbers we can calculate that the bore is 70 millimeters and the stroke is 97.4 millimeters. As we can see this is a ridiculously undersquare engine, probably the most undersquare mass-produced gasoline engine I have ever seen.
To put it into perspective here’s the Geely 1.5 I-HEV engine next to an old-school muscle car engine. We will use this juxtaposition to explain the benefits and the reasons behind such an undersquare design.
In an undersquare engine, we have a small bore, which means that we are limited in the amount of air and fuel we can pack in there. We are delivering a small punch. At the same time the very long stroke means that we will be able to extract more of the energy of our small punch because our piston has a longer distance to cover while traveling downward and extracting energy. But because the stroke is longer the piston must travel faster to cover it, which is why we can’t rev as high because at some point pistons speeds get so high that the engine destroys itself. But with an undersquare engine we usually don’t even want to rev to high because our priority isn’t making power it’s extracting all the energy from our clean little punches
But the undersquare anatomy alone isn’t enough to achieve the incredible thermal efficiency, you also need cringey branding, and so this engine also features something called a Fire Tornado Combustion System and a duckbill intake. In reality what this is is an intake anatomy that results in increased air velocity and air tumbling which improves air and fuel mixing leading to optimized combustion. To further optimize combustion the injection pressure has been increased to 500 bar which improves fuel vaporization. And to squeeze in every last bit of the energy of our super optimized air and fuel mixture, we have a 15.5:1 compression ratio and a deep miller combustion cycle. On top of this we have laser-clad valve seats, which are directly fused onto the cylinder head instead of being pressed in like traditional valve seats. This both improves cooling and enables more freedom of intake port design. The engine also features advanced surface treatments and machining as well as DLC coatings on many critical engine surfaces and moving parts for an impressive reduction in friction.
And there you have it. 48.41% thermal efficiency. At least, that’s the story according to the press release.
Now, if you’ve been following engine development in the last 10 years, you have probably noticed that this engine is about as innovative as a brick. See the direct comparison with a Toyota Dynamic Force engine in the video to see my point.
All the technologies present on the Geely 1.5 I-HEV engine can be found on engines from various European, Japanese and US manufacturers and they most certainly do not explain an efficiency improvement of 7.4%. So where does the improvement come from? It comes from a deep Miller cycle. It comes from there because that's the only place where it can come from.
A special thank you to my patrons:
Daniel
Peter Della Flora
valqk
Dave Westwood
Zwoa Meda Beda
Cole Philips
Allan Mackay
Sam Lutfi
Alex
00:00 Crazy Undersquare
05:35 Fire Tornado Cringe
07:30 Geely I-HEV vs Toyota Dynamic Force
08:46 Deep Miller Secret
12:18 Electrified ICE vs Combustionized EV
14:33 Are Electric-Centric Hybrids a Good Idea?
16:33 Fixing the Downsides With AI
